V-4440-1009
Water Valve, 3 Way, 5/8 in.
by
done_outline8888 in stock
addShow Locations
removeHide Locations
Flare Connection, For 4 Pipe System, 4.1 Max Cv Normally Closed Seat, 4.7 Cv Normally Open Seat, Cast Brass Body, Brass Plug, Stainless Steel Stem, 90 Degree Elbow Body Style.
Features
Supplied With A Factory Installed V-3000 Exposed Pneumatic Actuator, Which Has A Synthetic Rubber Diaphragm In A Die-Cast Aluminum Housing
Molded Diaphragm Provides A Constant Effective Area Throughout The Valve Stroke
Actuator Assembly Can Be Removed Without Disturbing The Remainder Of The Valve Assembly
Completely Enclosed Actuator Can Be Ordered Separately For Field Mounting
Valve Has 2 Inlets, Upper And Lower, And One Outlet, Center
Lower Inlet Port Is Normally Open And Upper Inlet Port Is Normally Closed
Both A Switch Valve And A Control Valve
Contains Two Modulating Plugs With Replaceable Composition Discs That Are Designed For Both Hot And Cold Water Service
Bottom Service Connection Is Furnished With A 90 Degree Elbow That Can Be Rotated To Any Position
Technical Details
Service
Hot And Cold Water
Operating Conditions
-10 F To 150 F (-23 C To 66 C)
Flow Characteristic
Characterized Modulating
Maximum Control Pressure
40 psig
