F680-150SHP+GMB24-3-X1
Butterfly Valve Assembly 2 Way, 3 in.
by
done_outline8888 in stock
addShow Locations
removeHide Locations
Flanged, 90 Degree At 228 Cv, Carbon Steel Full Lug Body, Reinforced Teflon Seat, Stainless Steel Disc, Direct Coupled Actuator, 360 in-lb, On/Off, Floating Point, Non-Spring Return, 24 VAC.
Features
Resilient Seat, Grooved And High Performance Butterfly Valves Meet A Wide Range Of Applications
Innovative Seat And Disc Design Provides Zero Percent Leakage Capability At Each Valves Rated Temperature/Pressure While Maintaining A Low Seating Torque
Stainless Steel Disc And Shaft Are Standard For Superior Durability And Long Lasting Operation
Technical Details
Service
Chilled Or Hot Water, Up To 60% Glycol, Steam
Flow Characteristic
Modified Equal Percentage, Unidirectional
Operating Conditions
-22 F To 122 F (-30 C To 50 C)
Close-Off Pressure
285 psi
Power Consumption
4 W Running, 2 W Holding
Operating Conditions
-22 F To 122 F (-30 C To 50 C)
Electrical Connection
3 ft. 18 GA Plenum Rated Cable, With 1/2 in. Conduit Connector
Housing
NEMA 2, IP54, UL Enclosure Type 2
