G220B-J+LF120 US

Globe Valve Assembly, 2 Way, 3/4 in.

done_outline8888 in stock

addShow Locations removeHide Locations

NPT, 5.5 Cv, Bronze Body, Bronze Seat, Stainless Steel Stem, Direct Coupled Actuator, 35 in-lb, On/Off, Spring Return Fail-Safe, 120 VAC.

Features

Typically Used In Air Handling Units On Heating Or Cooling Coils, And Fan Coil Unit Heating Or Cooling Coils

Suitable For Use In Hydronic Systems With Variable Flow

Technical Details

Service

Chilled Or Hot Water, Up To 60% Glycol, Steam

Flow Characteristic

Modified Equal Percentage

Operating Conditions

20 F To 280 F (-7 C To 138 C)

Power Consumption

2 W Running

Operating Conditions

-22 F To 122 F (-30 C To 50 C)

Electrical Connection

3 ft. 10 ft. 16 ft. 18 GA Plenum Rated Cable With 1/2 in. Conduit Connector

Housing

NEMA Type 2, IP54
