VBN2AGPA3001
Ball Valve Assembly, 2 Way, 1/2 in NPT
by
done_outline8888 in stock
addShow Locations
removeHide Locations
Characterized Control Valve, 26 Cv, Nickel Chrome Plated Brass, Direct Coupled Actuator, 27 in-lb, Non-Spring Return Fail In Place, 24 VAC, Modulating
Features
Sizes From 1/2 in To 3 in With Internal Female NPT Connections
Reduced B Port Cv For Constant Loop Flow
Field Configurable For Normally Open Or Normally Closed Fail-Safe Position
Removable Manual Operating Handle To Control Valve During Installation Or In An Event Of Power Failure
Actuator Can Be Mounted On The Valve In Any Of Four Orientations
Shield-Serviceable Stem Assembly
Wide Range Of Cv Choices From 033 To 299
Valve Installs In A Globe Valve T Pattern, No Extra Elbows Or Piping Required
Technical Details
Service
Hot And Chilled Water w/Glycol Solutions Up To 50%
Flow Characteristic
Equal Percentage
Operating Temperature
-22 F To 250 F (-30 C To 121 C)
Maximum Safe Operating Rating
360 psi
Power Consumption
6 VA
Operating Conditions
-4 F To 131 F (-20 C To 55 C)
Electrical Connection
Field Wiring 18 To 20 AWG To Screw Terminals, Located Under The Removable Access Cover
Housing
NEMA 2, IP40
