VA-7202-1001
Valve Actuator, 180 lb. Minimum Force
by
done_outline8888 in stock
addShow Locations
removeHide Locations
24 VAC, 0 To 10 VDC Or 0 To 20 mA, Proportional Control, 0 To 2000 ohms Potentiometer Feedback.
Features
Compact Unit Provides 180 lb. Force Output Covering A Wide Range Of Applications With Just One Actuator
Magnetic Clutch Provides Constant Output Force For Positive Close-Off Of Valves And Protects Motor In Stall Conditions
Durable Construction Provides Longer Cycle Life
Unique Yoke Design Enables Easy Field Mounting To Valves, Reducing Installation And Stroke Adjustment Time
Selectable Direct And Reverse Action Simplifies Setup And Installation
Built-In Resistor For Current Control Provides Greater Application Flexibility
Technical Details
Power Consumption
24 VAC
Operating Conditions
23 F To 131 F (-5 C To 55 C)
Electrical Connections
24 To 16 AWG Screw Terminals
Housing
NEMA 2, IP42
