VG1295CL+923GGA
Ball Valve Assembly, 2 Way, 1 in.
by
done_outline8888 in stock
addShow Locations
removeHide Locations
Press End Connection, 7.4 Cv, Forged Brass Body, Stainless Steel Ball And Blowout-Proof Stem, Direct Mount Electric Actuator, 27 lb-in. Spring Return, 24 VAC, 0 To 10 VDC, Proportional.
Features
Maintenance-Free Design, Performs Without Failure In Excess Of 200,000 Full Stroke Cycles In Iron-Oxide Contaminated Water
500:1 Rangeability, Provides Accurate Control Under All Load Conditions
Press End Connections Designed To Work With RIDGID Pressing Tools, Reducing Installation Costs
Technical Details
Service
Hot Water, Chilled Water, 50/50 Glycol Solution For HVAC Systems
Flow Characteristic
Equal Percentage
Operating Conditions
22F To 212 F (-30 C To 100 C)
Close-Off Pressure
200 psig
Power Consumption
5.0 VA Running, 2.5 VA Holding
Operating Conditions
-22 To 140 F (-30 C To 60 C)
Electrical Connection
48 in. 18 AWG Appliance Cables, 1/2 in. Conduit Connectors
Housing
NEMA 2, IP54
Auxiliary Switch
1 x SPDT
