VG7842NT+71CHGA
Globe Valve Assembly, 3 Way 1 in.
by
done_outline8888 in stock
addShow Locations
removeHide Locations
NPT, 11.6 Cv, Bronze Body, Stainless Steel Stem And Brass Against Molded Elastomeric Disk Seat, Direct Coupled Actuator, 180 in-lb Non-Spring Return, 0 To 10 VDC, Proportional.
Features
Long Life Replaceable Ring Packing Provides Highest Reliability And Longest Life
Meets Requirements Of ASME B16.15 Class 250
Every Valve Tested For Tight Shut-Off
Technical Details
Service
Hot Water, Chilled Water, 50/50 Glycol Solutions, And Steam For HVAC Systems
Operating Conditions
35 F To 284 F (2 C To 140 C)
Flow Characteristic
Linear
Closeoff Pressure
182/213 psig
Power Consumption
6 VA
Actuator Operating Conditions
23 F To 131 F (-5 C To 55 C)
Electrical Connection
48 in. UL 758 Type AWM Halogen-Free Cable With 18 AWG Conductors And 0.25 in. Ferrule Ends
Housing
NEMA 2, IP42
