MP-5230
Direct Coupled Actuator, 1.86 in-lb.
by
done_outline8888 in stock
addShow Locations removeHide Locations
Spring Return, 120 VAC, Modulating Control, 3 To 12 VDC Control Signal.

Features

Linear Motion Output Shaft Controlled By A Variable DC Voltage Input Signal
Nominal 3 VDC Operating Span
Fixed Start Point And Non-Positive Positioning
10,000 ohm Or Greater Input Impedance
Available In Damper Models Or Base Models That Require Damper Or Valve Linkage
Die Cast Lower Housing And Painted Steel Upper Housing
Hydraulic Actuator With Oil-Immersed Motor, Transducer And Pump
Internal Feedback Circuitry Provides Non-Positive Positioning Control In Relation To The Controller Signal

Technical Details

Power Consumption
120 VAC
Operating Conditions
-20 F To 140 F (-40 C To 60 C)
Electrical Connections
4 ft. Appliance Cables
Housing
NEMA 1
