GCA136.1P
Direct Coupled Actuator, 160 in-lb
by
done_outline8888 in stock
addShow Locations removeHide Locations
Spring Return, 24 VAC/DC, 7 VA, Floating Control.

Features

Brushless DC Motor Technology With Stall Protection
CE, UL60730, And cUL (C22.2 No. 24-93) Listed
Bi-Directional Fail-Safe Spring Return
Patented Self-Centering Shaft Coupling
All Metal Housing
Manual Override
5 Degree Preload As Shipped From Factory
Mechanical Range Adjustment Capability By Moving Shaft Coupling To Desired Position
Easily Visible Position Indicator
Precabled

Technical Details

Power Consumption
7 VA Running, 5 VA Holding
Operating Conditions
-25 F To 130 F (-32 C To 55 C)
Electrical Connection
3 ft. 18 AWG Plenum Cable
Housing
NEMA 2, IP54
Auxiliary Switches
Dual
