274-05950
Globe Valve Assembly, 2 Way, 2-1/2 in.
by
done_outline8888 in stock
addShow Locations
removeHide Locations
Flanged, 63 Cv, Bronze Trim, Direct Coupled Actuator, 250 in-lb, Spring Return, Normally Closed, 24 VAC, 17 VA, Modulating Control, 0 To 10 VDC Or 4 To 20 mA.
Features
ANSI Class 250
Technical Details
Service
Saturated Steam, Water, Glycol Solutions To 50%
Flow Characteristic
Equal Percentage
Operating Conditions
20 F To 250 F (-7 C To 120 C)
Close-Off Pressure
34 psi
Power Consumption
17 VA
Operating Conditions
5 F To 130 F (-15 C To 55 C)
Electrical Connections
1/2 in. NPSM Conduit Opening
Housing
NEMA 1
