VG12A5GS+924GGC
Ball Valve Assembly, 2 Way, 2-1/2 in
by
done_outline8888 in stock
addShow Locations
removeHide Locations
Flanged, 47 Cv, Brass Body, Stainless Steel Ball And Stem, Direct Mount Electric Actuator, 210 lb-in. Non-Spring Return, 24 VAC, 0 To 10 VDC, Proportional Control.
Features
Maintenance-Free Design, Performs Without Failure In Excess Of 200,000 Full Stroke Cycles In Iron-Oxide Contaminated Water
500:1 Rangeability, Provides Accurate Control Under All Load Conditions
Tight Shutoff
Technical Details
Service
Hot Water, Chilled Water, 50/50 Glycol Solution And 25 psig Saturated Steam For HVAC Systems
Flow Characteristic
Equal Percentage
Operating Conditions
0 F To 284 F (-18 C To 140 C)
Close-Off Pressure
100 psig
Power Consumption
7.5 VA
Operating Conditions
-4 F To 122 F (-20 C To 50 C)
Electrical Connection
1/4 in. Spade Terminals With Pluggable 3-Terminal Blocks
Housing
NEMA 2, IP42
Auxiliary Switches
2 x SPDT
