CMB24-SR-R
Direct Coupled Actuator, 18 in-lb
by
done_outline8888 in stock
addShow Locations
removeHide Locations
Modulating, Non-Spring Return, 24 VAC, For 2 To 10 VDC Or 4 To 20 mA Control Signal.
Features
Simple Direct Mounting On The Damper Spindle With A Universal Spindle Clamp Or Form Fit, Supplied With An Anti-Rotation Bracket To Prevent The Actuator From Rotating
Manual Operation Is Possible With A Magnet
Adjustable Angle Of Rotation With Mechanical End Stops, That Requires No Tools To Move Or Remove
Overload-Proof, Requires No Limit Switches And Automatically Stops When The End Stops Is Reached
Uses A Brushless DC Motor
Technical Details
Power Consumption
1.5 W Running
Operating Conditions
-22 F To 122 F (-30 C To 50 C)
Electrical Connection
3 ft. 18 GA Appliance Rated Cable Protected NEMA 2 (IP54)
Housing
NEMA 2, IP54, UL Enclosure Type 2
