R7999B1003/U

Discontinued

200 To 240 VAC, 50/60 Hz., Uses The Latest Microprocessor-Based Technology To Simultaneously Control Up To Four Actuators

Features

Fast Burner Setup Via PC Or Laptop

Field-Configurable Device

Integrated Boiler Shock Protection Algorithms: Water Temperature Low Fire Hold

Selectable FGR Hold Based On Stack Temperature

Fuel, Air, FGR Profile Download Capability

Two Independent Fuel Profiles With Or Without FGR

7 To 24 Point Profiles

Programmable Behaviors Of All Actuators During Purge And Standby

Independent Light Off And Minimum Modulation Positions

Manual Mode Firing Rate Input

Pluggable Controller To Wiring Subbase

Multipurpose Communications Port

Technical Details

Operating Conditions

-40 F To 140 F (-40 C To 60 C), 90% RH Maximum, Non-Condensing

Approvals

Underwriters Laboratories, Inc: Listed: Report No. MH17367
