GAP156.1P
Direct Coupled Actuator, 53 in-lb
by
done_outline8888 in stock
addShow Locations
removeHide Locations
Fail-In-Place, 24 VAC/DC, 28 VA, Modulating Control, 0 To 10 VDC, Self-Adapting.
Features
Fast Operation, 2 Second Runtime
Feedback Is Standard On All Models
Highly Accurate Positioning
Brushless DC Motor Technology With Stall Protection
Unique Self-Centering Shaft Coupling
UL And cUL Listed, CE Certified
Manual Override Capability
Self-Adapts Control Signal To A Reduces Mechanical Working Range
Technical Details
Power Consumption
28 VA Running, 8 VA Holding
Operating Conditions
0 F To 122 F (-18 C To 50 C)
Electrical Connection
3 ft. 18 AWG Cable
Housing
NEMA 1
Auxiliary Switches
Dual
