R7795D1005/U
Discontinued
by
120 VAC, 50/60 Hz., 120 VAC Output For Alarm Relay Switching, 3 Second Nominal Flame Failure Response Time, Full Function Primary Safety Control, Interrupted Pilot, Rectification.
Features
Provide Solid State, Electronic Flame Safeguard Protection For Commercial And Industrial Single Or Dual Fuel Burners
Include Flame Signal Amplifiers That Are Color-Coded: Purple For UV And Green For Rectification
Require A Plug-In Prepurge Timer Of 1.5, 7, 10, 30, 60, Or 90 Seconds
Mount On A Q795A Wiring Subbase With Two Captive Screws
Include Line Voltage Airflow Switch To Prove Airflow From The Start Of Prepurge Through The Run Period
Prevent Start-Up With Lockout If Flame Or A Flame Simulating Failure Exists
Technical Details
Safety Switch Timing
Electronic - 10 seconds, Mechanical - 15 seconds
Application
Provides Flameout Protection Plus Automatic control Of Commercial And Industrial Gas And Oil Burners
Operating Conditions
-40 F To 135 F
