VG7241NT+7202G

Globe Valve Assembly, 2 Way 1 in.

NPT, 11.6 Cv, Bronze Body, Stainless Steel Stem, And Brass Seat, Direct Coupled Actuator, 180 in-lb, Non-Spring Return, 0 To 10 VDC, Proportional.

Features

Magnetic Clutch Protects Gearing, Ensures Tight Closeoff

Factory Or Field Assembly

Valve Body Static Pressure Rating: ANSI Class 250

Technical Details

Service

Hot Water, Chilled Water, 50/50 Glycol Solutions, And Steam For HVAC Systems

Operating Conditions

35 F To 248 F (2 C To 120 C)

Flow Characteristic

Equal Percentage

Close-off Pressure

179 psig

Power Consumption

8.7 VA

Operating Conditions

23 F To 131 F (-5 F To 55 F)

Electrical Connection

Screw Terminals

Housing

NEMA 2, IP42
