VG7243NT+7203G
Globe Valve Assembly, 2 Way 1 in.
by
NPT, 11.6 Cv, Bronze Body, Stainless Steel And Seat, Direct Coupled, Non-Spring Return Electric Actuator, 180 in-lb, 24 VAC, On/Off, Floating With Feedback.
Features
Packing: Spring-Loaded PTFE And Elastomer V-Rings
Magnetic Clutch Protects Gearing, Ensures Tight Closeoff
Factory Or Field Assembly
Valve Body Static Pressure Rating: ANSI Class 250
Technical Details
Service
Hot Water, Chilled Water, 50/50 Glycol Solutions, And Steam For HVAC Systems
Operating Conditions
35 F To 338 F (2 C To 170 C)
Flow Characteristic
Equal Percentage
Close-off Pressure
112 psig
Power Consumption
8.7 VA
Actuator Operating Conditions
23 F To 131 F (-5 F To 55 F)
Electrical Connection
Screw Terminals
Housing
NEMA 2, IP42
