VG7844RT+72CHGA

Globe Valve Assembly, 3 Way 1-1/2 in

done_outline8888 in stock

addShow Locations removeHide Locations

NPT, 28.9 Cv, Bronze Body, Stainless Steel Stem And Seat, Electric Actuator, 180 in-lb Non-Spring Return, 0 To 10 VDC, Proportional.

Features

Meets Requirements Of American Society Of Mechanical Engineers (ASME) B16.15 Class 250

Long Life Replaceable Ring Packing Provides Highest Reliability And Longest Life

Every Valve Tested For Tight Shutoff

Technical Details

Service

Hot Water, Chilled Water, 50/50 Glycol Solutions, And 38 psig Saturated Steam For HVAC Systems

Operating Conditions

35 F To 338 F (2 C To 170 C)

Flow Characteristic

Linear

Closeoff Pressure

44/46 psig

Power Consumption

11 VA

Actuator Operating Conditions

23 F To 131 F (-5 C To 55 C)

Electrical Connection

48 in. UL 758 Type AWM Halogen-Free Cable With 18 AWG Conductors And 0.25 in. Ferrule Ends

Housing

NEMA 2, IP42
