Features

Slim design...minimizes space on DIN Rail.

Isolated input and output terminals...separates control circuits from load circuits

Contact viewing window...shows position of contacts

Technical Details

Operating Range

85% to 110% of rated voltage

Drop-out Voltage Threshold

15% of rated voltage

Expected Relay Life Electrical (@ rated current)

100,000 cycles

Mechanical (unpowered)

10,000,000 cycles

Operating Time

20 ms typical

Dielectric Strength

1500VAC (RMS)

Operating Temperature

-40° to 55°C (-40° to 131°F)
